(GD) - Glue Down Luxury Vinyl 2mm 12mil
Specifications
Technical Data
Specifications
| Length | 48″ | Width | 7.25″ |
| Thickness | 2mm | Wear Layer | 12mil |
| Finish | Emboss | Edge Description | Micro Bevel |
| Sqft/Box | 58.00 | lb/Box | 47.0 |
| Box/Plt | 60 | Sqft/Plt | 3480 |
| lb/Plt | 2823 | Plt/FTL | 15 |
| Limited Residential Warranty | Lifetime | Limited Commercial Warranty | 10Years |
Technical Data
| Characteristics | Standards | Requirements | Result |
| TUV Premium Certification | Belgian VOC regulation BREEAM Exemplary Level | Refer to Standards | Pass |
| CE Certification | EN14041 | Refer to Standards | Pass |
| Floorscore Certification | SCS-EC10.3-2014v3.0 | Refer to Standards | Pass |
| Staining resistance | EN 423:2001 | N/A | Not affected |
| Chemical Solution | EN423:2002 | N/A | Not affected |
| Colour fastness to light | ISO 105 B02:1994 /Amd 1:1998+Amd 2:2000 | N/A | Grade 6 |
| Peel resistance | EN 431:1994 | N/A | Upper layer: (X diection:90N/50mm, Y diection:90N/50mm) |
| Slip resistance | DIN 51130:2010 EN13893 | Coefficient of Friction≥0.30 | R10 Class DS |
| Fire resistance | EN 9239-1 EN ISO11925-2 EN 13501-1 | Critical Fluxf≥8.0kW/m2 Fs≤150mm within 20s Smoke≤750% minutes | Bfl-S1 |
| Determination of residual indentation after static loading | EN433:1994 | N/A | 0.038mm Pass 0.04mm |
| Dimensional stability and curling after exposure to heat | EN 434 :1994 | ≤0.25% The curling ≤ 2mm | variation of X direction:-0.13% variation of Y direction:-0.12% Curling:<0.5mm |
| Water Absorption | ASTM D570-98(2010) | 0.17% Pass | |
| Phthalate tests (DBP/BBP/DEHP/DINP/ DNOP/DIDP) | EN 14372:2004 REACH NO.1907/2006 REACH NO.552/2009 | N/A | Free |
| Formaldehyde Emission | EN717-1:2004 | E1≤0.124mg/m3 | Free |
| Soluble heavy metal contents test | EN 71 Part 3:1994+ A1:2000+AC:2002 ASTM F 963-11 | N/A | Free |
| SVHC Released | EU REACH Regulation No.1907/2006 Article 33 | N/A | Not Detected |
| VOCs Acetaldehyde | ASTM CA 01350 v1.1,2012 | N/A | Pass |
| VOCs Toluene | ASTM CA 01350 v1.1,2012 | N/A | Pass |
| TVOC | ASTM CA 01350 v1.1,2012 | N/A | Pass |
| French VOC Regulation | ISO16000 parts-3,-6,-9,-11 | N/A | A+ |
